• The included setting tool combines the drilling and fixing setting functions. It thus allows for a fast and simple installation.
• The sharp, self-tapping thread of the GK enables a secure, positive fit fixing. This achieves a high load-bearing capacity.
• The short fixing length means that only a small amount of space is required behind the board. As a result, the GK can also be used in the case of unknown board thickness and cavity depth.
• The cross-drive recess in the head of the fixing means that the GK can also be screwed out like a screw without a setting tool.
• The GK can be used with the most wide-ranging screws, hooks and eye screws. This allows for a broad range of applications.

Applications

• Pictures
• Lighting
• Electrical installations
• Fitting accessories
• Series installations

Building materials

• Gypsum plasterboard, single and double-planked

You can find detailed information on building materials in the approval document.

Functionality

• The gypsum plasterboard fixing GK is suitable for pre-positioned installation.
• The GK is screwed flush into the gypsum plasterboard using the setting tool provided. Overtightening the fixing should be avoided. Therefore, the installation torque should be limited when using a battery operated screwdriver.
• Adapted for wood, self-tapping and chipboard screws of 4.0 to 5.0 mm diameter.
• For board thicknesses greater than 15 mm, drill a hole first by using the setting tool.
• Not suitable for gypsum fibreboard and tiled plasterboard.

Visit Fischer website for more info

Load Table
