Foliage specifications are recommendations only and may need to be adapted to suit your needs.
Maximum recommended Tension Load in short run wire systems is 15kg.
Not recommended for situations where there is a risk to the watertightness of a building e.g plaster and timber cladding.

Home
/ Foliage Systems
/ Foliage System Enquiry Form

Our stainless steel wire foliage system gives your wall a modern look and brings it to life! Made from 316 stainless steel, Anzor's foliage system requires less maintenance and lasts significantly longer than standard wooden trellis.

Check out these inspiring application images to see how a foliage system can transform your wall or project!

Click below for more information on system types:

Short wire run for less than 10m long
Stand Offs should be installed every 1.2m to support wire run.

Below is an example of a low profile setup for concrete.

Item

Product Code

Component

MFEBM6...

Eye Bolt with Drop In Anchor

MFSO...

Wire Stand Off

MFW02.50119

Wire Cross over Clamp

System Type	Item	Components (All components are 316SS)	Product Code
Low Profile Short Run for Wood	a.	8 x 60mm Cast Eye Screw	MFESM608060
	b.	2.5mm X M5 Swage Stud	MFSWS4W02.5M05
	c.	M5 X 30mm Pan Socket Drive Barrel Nut	NTBPM605K
	d.	2.5mm 1/19 Wire	MFW02.50119
Low Profile for Concrete	a.	M8 X 50mm Small Diameter Eye Bolt	MFEBM608050S
	b.	2.5mm X M5 Swage Stud	MFSWS4W02.5M05
	c.	M5 X 30mm Pan Socket Drive Barrel Nut	NTBPM605K
	d.	2.5mm 1/19 Wire	MFW02.50119
	e.	M8 Drop In Anchor	DYDIM608
Tall Profile for Wood	a.	M10 X 100mm Wire Stand Off Eye Screw & Washer	MFSOLESW10100
	b.	2.5mm X M5 Swage Stud	MFSWS4W02.5M05
	c.	M5 X 30mm Pan Socket Drive Barrel Nut	NTBPM605K
	d.	2.5mm 1/19 Wire	MFW02.50119
Tall Profile for Concrete	a.	M10 X 100mm Wire Stand Off Eye Bolt & Washer	MFSOEBM10100
	b.	2.5mm X M5 Swage Stud	MFSWS4W02.5M05
	c.	M5 X 30mm Pan Socket Drive Barrel Nut	NTBPM605K
	d.	2.5mm 1/19 Wire	MFW02.50119
	e.	M10 Drop In Anchor	DYDIM610

Long Run Foliage System Dimension Example

Long wire run for more than 10m long
First Stand Off to be 500mm from Anchor Eye
Subsequent Stand Offs to be at 2m intervals

Anchor Eye
Wire Stand Off
Wire Cross over Clamp

System Type	Item	Components All components are 316SS	Code
Long Run for Wood	a	M10 X 20 Standoff Anchor Eye Screw & Washer	MFSOLESW1020
	b	M6 Socket Drive D Shackle	MFDSOKM606
	c	3mm X M6 Jaw/Swage Pipe Turnbuckle	MFTBPJSM606
	d	3mm 1/19 Wire	MFW030119
	e	M10 X 100 Wire Stand Off Eye Screw & Washer	MFSOLESW10100
Long Run for Concrete	a	M10 X 20 Stand Off Anchor Eye Bolt & Washer	MFSOLESW1020
	b	M6 Socket Drive D Shackle	MFDSOKM606
	c	3mm X M6 Jaw/Swage Pipe Turnbuckle	MFTBPJSM606
	d	3mm 1/19 Wire	MFW030119
	e	M10 Drop In Anchor	DYDIM610
	f	M10 X 100 Wire Stand Off Eye Bolt & Washer	MFSOEBM10100

Complete numbered steps in the enquiry form below to receive a quote within 2 business days. Review and edit component quantities carefully before submitting your request.

1. Enter Foliage Details

Length of a Single Run

Preferred Distance Between Anchors

Total Number of Runs

2. Select Foliage System

Short Run Systems For wire spans less than 10m

Low Profile for Wood

View components

Low Profile for Concrete

View components

Tall Profile for Wood

View components

Tall Profile for Concrete

View components

Long Run Systems For wire spans greater than 10m

Long Run for Wood

View components

Long Run for Concrete

View components

Calculated Quantity Needed:
Based on the details you provided above, you will need the following items. Note as numbers are approximate please change any component quantities as required to suit your design or producer statement needs before submitting your request. Please note if you are logged in this contact form will preload some user details.

Please note if you are logged in this contact form will preload some of your details.

First Name*

Last Name*

Company Name

Email*

Phone*

Your Local Branch?*

Comments

Length of Wire in mm

Barrel Nuts

Turnbuckles

Eye Bolt/Screw

Drop In Anchors

Wire Standoffs

D Shackles

Swage Stud

Wire Cross Over Clamps (Longer)

Please enter the total number of Wire Cross Over Clamps you will require for your system.

Anzor's Stainless Wire Balustrading System

This stainless steel wire system offers a flexible and permanent trellis, bringing featureless walls and fences to life.

Modernise a wall or fence by growing foliage over a stainless steel wire trellis.

This stainless steel wire system provides a strong and lightweight trellis, offering a flexible and permanent solution that transforms plain walls and fences.

	Component Code	Component Name
a.	MFESM608060	8 X 60mm Cast Eye Screw
b.	MFSWS4W02.5M05	2.5mm X M5 Swage Stud
c.	NTBPM605K	M5 x 30mm Pan Socket Drive Barrel Nut
d.	MFW02.50119	2.5mm 1/19 Wire
3.	ACCSCW03L	M3 316 Wire Cross Over Clamp (24mm Long)

	Component Code	Component Name
a.	MFEBM608050S	M8 X 50mm Small Diameter Eye Bolt
b.	MFSWS4W02.5M05	2.5mm x M5 Swage Stud
c.	NTBM605K	M5 X 30mm Pan Socket Drive Barrel Nut
d.	MFW02.50119	2.5mm 1/19 Wire
e.	DYDIM608	M8 Drop In Anchor
3.	ACCSCW03L	M3 316 Wire Cross Over Clamp (24mm Long)

	Component Code	Component Name
a.	MFSOLESW10100	M10 x 100mm Wire Stand Off Eye Screw & Washer
b.	MFSWS4W02.5M05	2.5mm x M5 Swage Stud
c.	NTBPM605K	M5 X 30mm Pan Socket Drive Barrel Nut
d.	MFW02.50119	2.5mm 1/19 Wire
3.	ACCSCW03L	M3 316 Wire Cross Over Clamp (24mm Long)

	Component Code	Component Name
a.	MFSOEBM10100	M10 X 100mm Wire Stand Off Eye Bolt & Washer
b.	MFSWS4W02.5M05	2.5mm X M5 Swage Stud
c.	NTBPM605K	M5 X 30 Pan Socket Drive Barrel Nut
d.	MFW02.50119	2.5mm 1/19 Wire
e.	DYDIM608	M10 Drop In Anchor
3.	ACCSCW03L	M3 316 Wire Cross Over Clamp (24mm Long)

	Component Code	Component Name
a.	MFSOLEBM10020	M10 X 20 Stand Off Anchor Eye Bolt & Washer
b.	MFDSCKM606	M6 Socket Drive D Shackle
c.	MFTBPJSM606	3mm x M6 Jaw/Swage Pipe Turnbuckle
d.	MFW030119	3mm 1/19 Wire
e.	DYDIM610	M10 Drop In Anchor
f.	MFSOEBM10100	M10 X 100 Wire Stand Off Eye Bolt & Washer
3.	ACCSCW03L	M3 316 Wire Cross Over Clamp (24mm Long)

	Component Code	Component Name
a.	MFSOLESW10020	M10 X 20 Stand Off Anchor Eye Screw & Washer
b.	MFDSCKM606	M6 Socket Drive D Shackle
c.	MFTBPJSM606	3mm x M6 Jaw/Swage Pipe Turnbuckle
d.	MFW030119	3mm 1/19 Wire
e.	MFSOLESW10100	M10 X 100 Stand Off Anchor Eye Screw & Washer
3.	ACCSCW03L	M3 316 Wire Cross Over Clamp (24mm Long)
